An extensive range of scopes to suit all calibres and disciplines.
All Vantage riflescopes feature our H2 optics in a variety of configurations.
The unprecedented Fiber Dot reticles give an intensely bright red illuminated center dot that really can be called daylight bright.
- Capped Low-Profile Turrets
- 30mm Mono-tube chassis
- Wide Angle
- Fibre Optic Illumination
- 11 layer Fully Multi-Coated lenses
- High torque zoom ring
- Fast focus eyebell
- Supplied with removable zoom lever
Nitrogen purged. Shockproof. Waterproof. Fog proof.
All calibre rated.
Hawke No-Fault Lifetime Warranty.
Product Type
Riflescope
Product Range
Vantage 30 WA FD IR
Optical System
System H2
Scope Tube
30mm
Magnification
3 - 12x
Objective Lens
56mm
Reticle
L4A FD
Illumination
11 Levels - Red
Parallax
Fixed
Focal Plane
SFP (Second Focal Plane)
Lens Coating
Fully Multi-Coated - 11 Layers
Field of View (ft@100yds)
43.8 - 11.4
Field of View (m@100m)
14.6 - 3.8
Field of View (°)
8.3 - 2.2
Eye Relief (in)
3.5
Eye Relief (mm)
90
PX/Focus (yds)
100
PX/Focus (m)
91
Exit Pupil (mm)
18.7 - 4.7
Exit Pupil (in)
0.74 - 0.19
Turret Type
Capped
Turret Caps
YES
Click Value
1/4 MOA
Elevation Turret Clicks (max)
100 MOA
Windage Turret Clicks (max)
100 MOA
Ocular Type
Fast Focus
Power Selector
Knurled Posi-Grip with Removable Zoom Lever
Length (in)
13.3
Length (mm)
339
Weight (oz)
22.8
Weight (g)
645
Reticle Group
L4A FD
